40 Taper - OKK - BM
Main SpecificationX Axis Travel 84.3″ (2140mm) Y Axis Travel 51.2″ (1300mm) Z Axis Travel 24.0″ (610mm) Table Top to Spindle Nose 7.9″ – 31.9″ (200mm – 810mm) Table Work Surface Area 98.4″ x 57.5″ (2500mm x 1460mm) Table Load Capacity 13,200 lbs (6000 kg) Rapid Traverse Rate X 787 in/min (20 m/min) Rapid Traverse Rate Y/Z 945 in/min (24 m/min) Cutting Feed (X/Y/Z) 787 in/min (20 m/min) Spindle Power 40/34 HP Spindle Speed 12,000 rpm Spindle Taper BT40 Standard Number of Tools 40 Maximum Tool Weight 44 lbs (20 kg) Maximum Tool Length 15.8″ (400 mm) Maximum Tool Diameter ø 4.5″ (115 mm) / ø 9.1″ (230 mm) no tool in adjacent pot Tool Changing Time- Tool to Tool 2.8 sec Machine Weight 63,900 lbs (29,000 kg) Machine Control FANUC F31i-B
Main SpecificationX Axis Travel 1600 (62.99″) Y Axis Travel 1300 (51.18″) Z Axis Travel 460 (18.11″) Rapid Tranverse Rate X,Y:48m/min(1890ipm), Z:36m/min (1417ipm) Spindle Speeds 100 to 12,000 Spindle Motor AC7.5/5.5 kW(10/7.5HP) OP:22/18.5 kW(30/25HP) Spindle Taper No.40
Specification
Travel（X/Y/Z) 2200/1800/460mm Table size 2200x1800mm Max. loadable weight 3000kg Rapid speed XY：24m/min 　Z：36m/min Spindle speed 12000(OP：14000,20000)min-1 Spindle taper No. 40 Magazine capacity 40 (OP：60,80,120)
Main SpecificationX Axis Travel 3050 (120.08″) Y Axis Travel 2200 (86.81″) Z Axis Travel 460 (18.11″) Rapid Tranverse Rate X,Y:16m/min(630ipm), Z:36m/min (1417ipm) Spindle Speeds 100 to 12,000 Spindle Motor AC7.5/5.5 kW(10/7.5HP) OP:22/18.5 kW(30/25HP) Spindle Taper No.40
Main SpecificationX Axis Travel 137.8″ (3500mm) Y Axis Travel 122.1″ (3100mm) Z Axis Travel 22.1″ (560mm) Rapid Tranverse Rate 472 in/min (12 m/min), 1,260 in/min (32 m/min) Spindle Speeds 12,000 rpm Spindle Motor 10/7 HP Spindle Taper BT40 Table Work Surface Area 141.7″ x 108.3″ (3600mm x 2750mm) Table Load Capacity 8800 lbs (4000 kg) Standard Number of Tools 40 (60/80/120) Maximum Tool Weight 15 lbs (7 kg) Maximum Tool Length 11.8″ (300 mm) Maximum Tool Diameter ø 3.2″ (82 mm) Tool Changing Time- Tool to Tool 3.2 sec Machine Weight 90,300 lbs (41,000 kg) Machine Control FANUC 180is-MB
Main SpecificationX Axis Travel 1120 (44.09″) Y Axis Travel 920 (36.22″) Z Axis Travel 560 (22.050″) Rapid Tranverse Rate XYZ:32m/mn (1260ipm) Spindle Speeds 100 to 12,000 (OP: 20,000) Spindle Motor 30/25HP Magazine Capacity 40 (OP: 60, 80, 120) Spindle Taper No.40
