• Specifications

    DescriptionUnitGA-3600ML
    CAPACITYMax. / Swing over saddlemm(in)599 mm (23.6″)
    Max. Turning Diametermm(in) 500 mm (19.7″)
    Max. Turning Lengthmm(in)597 mm (23.5″)
    Bar Capacitymm(in)104 mm (4.1’)
    SPINDLEChuck Size(in)(15″)
    Hole through spindlemm(in)121 mm (4.76″)
    Spindle Speed (rpm)rpm2,500 rpm
    Motor output ( cont. / 30 min.)Hp / kW18.5  / 22 kW ( 25 / 30 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeDirect Belt Drive
    Spindle NoseA2-11
    FEEDTravel (X/Z)mm(in)260mm (10.23’) / 630mm (24.80’)
    Rapid Travel (X/Z)m/min24 m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)4 HP (2.7 kW)
    Z-axis servo motorHP (KW)6 HP (4.5 kW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)25 mm (1”)
    ID   mm(in)40mm (1”)
    TANK CAPACITYCoolant TankGallon / litre38 gal (145L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA38 kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)3,495 x 2,020 x 1,910 mm (137.5″ x 79.5″ x 75.1″ )
    Weightkg(lb)7,000 kg ( 15,400 lb )
    NCControllerFANUC Oi-TD
  • Specifications

    DescriptionUnitGS-4000ML
    CAPACITYMax. / Swing over saddlemm(in)770 mm (30.3″)
    Max. Turning Diametermm(in) 620 mm (24.4″)
    Max. Turning Lengthmm(in)818 mm (32.2″)
    Bar Capacitymm(in)114 mm (4.5’)
    SPINDLEChuck Size(in)(15″)
    Hole through spindlemm(in)130 mm (5.12″)
    Spindle Speed (rpm)rpm2,000 rpm
    Motor output ( cont. / 30 min.)Hp / kW30 / 37 kW ( 40 / 50 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle Type2-Speed Gear Box
    Spindle NoseA2-11
    FEEDTravel (X/Z)mm(in)350mm (13.78’) / 850mm (33.46’)
    Rapid Travel (X/Z)m/min24 m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)
    Z-axis servo motorHP (KW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)32 mm (1”)
    ID   mm(in)60mm (2”)
    TANK CAPACITYCoolant TankGallon / litre85 gal (330L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA65 kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)4,700 × 2,480 × 2,120 mm ( 185″ x 97″ x 84″ )
    Weightkg(lb)8,000 kg ( 17,637 lb )
    NCControllerFANUC Oi-TD
  • Specifications

    DescriptionUnitGS-4000YL
    CAPACITYMax. / Swing over saddlemm(in)770 mm (30.3″)
    Max. Turning Diametermm(in) 620 mm (24.4″)
    Max. Turning Lengthmm(in)818 mm (32.2″)
    Bar Capacitymm(in)114 mm (4.5’)
    SPINDLEChuck Size(in)(15″)
    Hole through spindlemm(in)130 mm (5.11″)
    Spindle Speed (rpm)rpm2,000 rpm
    Motor output ( cont. / 30 min.)Hp / kW30 / 37 kW ( 40 / 50 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle Type2-Speed Gear Box
    Spindle NoseA2-11
    FEEDTravel (X/Z)mm(in)350mm (13.78’) / 850mm (33.46’)
    Rapid Travel (X/Z)m/min24 m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)9.5 HP (7 kW)
    Y-axis servo motorHP (KW)4 HP (3 kW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)
    ID   mm(in)
    TANK CAPACITYCoolant TankGallon / litre85 gal (330L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA65 kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)4,700 × 2,480 × 2,120 mm ( 185″ x 97″ x 84″ )
    Weightkg(lb)8,000 kg (17,637 lb)
    NCControllerFANUC Oi-TD
  • Specifications

    DescriptionUnitGS-6000ML
    CAPACITYMax. / Swing over saddlemm(in)980 mm (38.6″)
    Max. Turning Diametermm(in) 879 mm (34.6″)
    Max. Turning Lengthmm(in)950 mm (37.4″)
    Bar Capacitymm(in)114 mm (4.5’)
    SPINDLEChuck Size(in)(15″)
    Hole through spindlemm(in)130 mm (5.11″)
    Spindle Speed (rpm)rpm1,200 rpm
    Motor output ( cont. / 30 min.)Hp / kW30 / 37 kW ( 40 / 50 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeV-Belt + Gear Box
    Spindle NoseA2-11
    FEEDTravel (X/Z)mm(in)500mm (19.68’) / 980mm (38.58’)
    Rapid Travel (X/Z)m/min24 m/min
    Slide TypeBox Ways
    X-axis servo motorHP (KW)
    Z-axis servo motorHP (KW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)32 mm (1”)
    ID   mm(in)60mm (2”)
    TANK CAPACITYCoolant TankGallon / litre63 gal (240L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA64 kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)145.51″ x 95.27″ x 101.10″ ( 3,696 x 2,420 x 2,568 mm )
    Weightkg(lb)12,000 kg ( 26,450 lb )
    NCControllerOi-TD
