Hyundai Wia L800MD

Compare Hyundai Wia L800MD with other machines in its class , , ,

In stock

Specifications

Description Unit L800MD
Max Turning Dia in 36.22
Max Turning Length in 65
Chuck Size in 34″ ~
Driving Method GEAR
Spindle RPM r/min 500
Spindle Output (max/cont.) hp 60 / 50
Spindle Torque (max/cont.) ft.lbs 5375 / 4420
Travel(X/Z) in 19.7/66
Rapid Travel(X/Z) in/min 472/630
Slide Type BOX
No. of Tools EA 12
Tool Size (ID/OD) in 1.25″ / 3 “
Milling Tool Speed r/min 3,000

Specifications are subject to change without notice for quality improvement.

Features

  • Sturdiness secured through the adoption of an all Axis box guide
  • All-in-one type structure with direct link for high accuracy and sturdiness
  • Based on double anchor method for high accuracy pretension
  • Minimized heat deformation in the main spindle
  • Gear box used for the main spindle (L600/700 Series : 3 step/ L800 Series : 2 step)
  • Big-bore main spindle with a maximum through diameter of Ø375 (Ø14.7″) (L800D)
  • Structural design featuring the major axis capable of processing a maximum length of 3,250mm (127.9″) (Long Bed Type)

Specifications

Description Unit L800D L800MD L800LD L800LMD
Max Turning Dia in 36.22
Max Turning Length in 62 65 128
Chuck Size in 34″ ~
Driving Method GEAR
Spindle RPM r/min 500
Spindle Output (max/cont.) hp 60 / 50
Spindle Torque (max/cont.) ft.lbs 5375 / 4420
Travel(X/Z) in 19.7/66 19.7/130
Rapid Travel(X/Z) in/min 472/630 472/472
Slide Type BOX
No. of Tools EA 12
Tool Size (ID/OD) in 1.25″ / 3 “
Milling Tool Speed r/min 3,000 3,000

Specifications are subject to change without notice for quality improvement.
