HYUNDAI WIA KIT4500

Compare HYUNDAI WIA KIT4500 with other machines in its class , ,

In stock

DescriptionUnitKIT4500
Max Turning Diameterinch6.5″
Max Turning Lengthinch11.8″
Table Sizeinch7.9″×21.7″
Chuck Sizeinch6″
Driving MethodBelt
Spindle RPMr/min6,000
Spindle OutputHP20/15
Spindle Torquelbf.ft70.5/51.6
Travel(X/Z)inch17.7″/11.8″
Rapid Travel(X/Z)in/min1181/1417
Slide TypeLM
No. of ToolsEA6
Tool Sizeinch0.75″/1.25″

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

Technical Leader

The Gang Type CNC Turning Center KIT4500, designed
by Hyundai WIA with years of expertise and the latest
technology, is a gang tool CNC Turning Center which
maximizes productivity through high speed and high
performance mechanisms.

Features

  • 60° slanted one-piece rigid bed structure
  • Realization of high-precision product processing through the reduction of combined thermal displacement
  • Decrease in belt damage and vibration in the main shaft by reducing the length of the main shaft belt
  • Optimum design for automated response
  • Compact design, able to install within a narrow space





Outstanding Productivity

High Precision, Rigid Mechanism Gang Type CNC Turning Center

Gang Type Block Tool

With Tool-To-Tool time reduced, productivity has bas improved in the machining of small sized parts.

images



Optimal structure for user convenience

Door opening width : 495mm (19.5″)

  1. Arrangement of hydraulic unit on the backend
  2. 2-directional (front / left side) pressure controller
  3. Top hole for the dust collector installation
  4. Sockets for piping option such as air tool, hydraulic, etc. (3 points)

images



Coolant tank performance improvement

Coolant Capacity : 120ℓ (31.7 gal)
{Compared to previous machine 20ℓ(5.3 gal) UP}

  1. Enhanced coolant filter capability

    Filter capability has been improved by applying a dual filter in the zigzag filtering partition structure.

  2. Leakage prevention struction

    Leak is prevented by tightening the chip box shoot surface close to the bed shoot floor through controlling the chip box height.

  3. Expansion of chip storage space

    The chip storage space under the bed has been expanded by 30% compared to the previous model.

images
