Hyundai Wia LV500R/L

Compare Hyundai Wia LV500R/L with other machines in its class , , ,

In stock

Specifications

DescriptionUnitLV500R/L
Max Turning Diain21.65
Max Turning Lengthin23.62
Chuck Sizein15″
Driving MethodBelt
Spindle RPMr/min2,000
Spindle Output (max/cont.)hp30/25
Spindle Torque (max/cont.)ft.lbs607/511
Travel(X/Z)in12.8/24.6
Rapid Travel(X/Z)in/min787/708
Slide TypeLM
No. of ToolsEA8[12]
Tool Size (ID/OD)in1.25″ / 2″
Milling Tool Speedr/min

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

Hyundai Wia LV500R/L

Features

  • Stable structure of the main spindle of powerful heavy cutting type (Loading & clamping structure taking advantage of the Spindle weight)
  • 2-step chuck pressure mechanism adopted to minimize material deformation
  • Various peripheral equipment can be used for rational machining
  • All-in-one machine structure incorporating power and oil supply functions in one body
  • Space design taking into account smooth ship treatment
  • “Right” and “Left” structure for the formation of rational automation

Specifications

DescriptionUnitLV500R/LLV500RM/LM
Max Turning Diain21.65
Max Turning Lengthin23.62
Chuck Sizein15″
Driving MethodBelt
Spindle RPMr/min2,000
Spindle Output (max/cont.)hp30/25
Spindle Torque (max/cont.)ft.lbs607/511
Travel(X/Z)in12.8/24.6
Rapid Travel(X/Z)in/min787/708
Slide TypeLM
No. of ToolsEA8[12]
Tool Size (ID/OD)in1.25″ / 2″
Milling Tool Speedr/min3,000

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
