Hyundai Wia KH1000

In stock

Travel (X / Y / Z)
82.7″ / 53.1″ / 55.1″

Specifications

Description Unit KH1000
Pallets Size inch 39.4″×39.4″
Max. Load Capacity lbf 2 – 6,614
Spindle Driving Method GEAR(2STEP)
Spindle Taper BBT50
Spindle RPM r/min 8,000
Spindle Power HP 34.8/29.5
Spindle Torque lbf.ft 595.2/505.9
Travel(X/Y/Z) inch 82.7″/53.1″/55.1″
Rapid Feed Rate(X/Y/Z) in/min 787/787/787
Slide Type BOX
No. of Tools EA 60
Tool Change Time
(Chip To Chip)
sec 16.7
No. of Pallets EA 2
APC Type SHUTTLE
Pallet Change Time sec 110

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

kh1000 Hyundai Wia

Features

  • Largest work area in its class with maximum processing size of 1,900 (74.8″) and 1,500mm (59″) height
  • High-torque 8,000 and 4,500rpm spindles available
  • Big Plus #50 2 Step Geared Spindle
  • Spindle Oil Cooling System for high accuracy
  • Shuttle Type Automatic Pallet Changer
  • Box Guides on All Axis for Superior Rigidity
  • Y axis box guideways with 8 face contact
  • Specially Designed Column which Minimizes Thermal Displacement

kh1000 Hyundai Wia Control

Specifications

Description Unit KH1000
Pallets Size inch 39.4″×39.4″
Max. Load Capacity lbf 2 – 6,614
Spindle Driving Method GEAR(2STEP)
Spindle Taper BBT50
Spindle RPM r/min 8,000
Spindle Power HP 34.8/29.5
Spindle Torque lbf.ft 595.2/505.9
Travel(X/Y/Z) inch 82.7″/53.1″/55.1″
Rapid Feed Rate(X/Y/Z) in/min 787/787/787
Slide Type BOX
No. of Tools EA 60
Tool Change Time
(Chip To Chip)
sec 16.7
No. of Pallets EA 2
APC Type SHUTTLE
Pallet Change Time sec 110

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
