Hyundai Wia KH80G

In stock

Specifications

Description Unit KH80G
Pallets Size inch 31.5″×31.5″
Max. Load Capacity lbf 2 – 4,850
Spindle Driving Method GEAR
Spindle Taper BT50
Spindle RPM r/min 4,500
Spindle Power HP 35/30
Spindle Torque lbf.ft 1,106.3/940.4
Travel(X/Y/Z) inch 49.2″/39.4″/33.5″
Rapid Feed Rate(X/Y/Z) m/min 18/18/18
Slide Type LM
No. of Tools EA 40
Tool Change Time
(Chip To Chip)
sec 9.5
No. of Pallets EA 2
APC Type SHUTTLE
Pallet Change Time sec 28

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalogue.

Features

  • Largest work area in its class with maximum processing size of 1,150(45.2″) and 1,150mm(45.2″) height
  • Big Plus #50 2 Step Geared Spindle (Option)
  • 3 Step Gear Main Spindles for heavy cutting conditions
  • Spindle Oil Cooling System for high accuracy
  • Shuttle Type Automatic Pallet Changer
  • Optimized Guide Ways on Each Axis
  • Specially Designed Column which Minimizes Thermal Displacement

Specifications

Description Unit KH80G
Pallets Size inch 31.5″×31.5″
Max. Load Capacity lbf 2 – 4,850
Spindle Driving Method GEAR
Spindle Taper BT50
Spindle RPM r/min 4,500
Spindle Power HP 35/30
Spindle Torque lbf.ft 1,106.3/940.4
Travel(X/Y/Z) inch 49.2″/39.4″/33.5″
Rapid Feed Rate(X/Y/Z) m/min 18/18/18
Slide Type LM
No. of Tools EA 40
Tool Change Time
(Chip To Chip)
sec 9.5
No. of Pallets EA 2
APC Type SHUTTLE
Pallet Change Time sec 28

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalogue.
