Compare Hyundai Wia LF1600M/2SP with other machines in its class 6 inch, Horizontal Turning Centers, Hyundai Wai, Live Tooling Turret
| Description | Unit | LF1600M/2SP |
|---|---|---|
| Max Turning Dia | inch | 10.2″ |
| Max Turning Length | inch | 6.5″ |
| Chuck Size | inch | 6″ |
| Driving Method | – | Belt |
| Spindle RPM | r/min | 4,500 |
| Spindle Output | HP | 7.4/10 |
| Spindle Torque | ft.lb | 25.5/34.8 |
| Travel(X/Z) | inch | 5.5″/6.5″ |
| Rapid Travel(X/Z) | m/min | 945/945 |
| Slide Type | – | BOX |
| No. of Tools | EA | 2 x 10 |
| Tool Size (ID/OD) | inch | 0.75″/1.25″ |
| Milling Tool Speed | r/min | 4000 |
| CNC | – | F31i |
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
