Hyundai Wia SE2200LMA

Compare Hyundai Wia SE2200LMA with other machines in its class ,

In stock

Description Unit SE2200LMA
Max Turning Dia inch 13.75″
Max Turning Length inch 12.16″
Chuck Size inch 6″
Driving Method Belt
Spindle RPM r/min 6,000
Spindle Output HP 20
Spindle Torque lbf.ft 93
Travel(X/Z) inch 8.3″/22″
Rapid Travel(X/Z) m/min 1181 / 1417
Slide Type Roller LM Guide
No. of Tools EA 12
Tool Size inch 0.75″/1.25″
Milling Tool Speed r/min 6000
Mill Motor Power HP 3.69

Features

  • 30° slanted one-piece bed structure with high rigidity
  • Ensured high rigidity applying Roller guideway on all axes (X/Z-axis: 30/36m/min)
  • Improved user convenience by applying the latest controller of FANUC
  • Prepared user-oriented lineup including long-bed, mill turret and sub-spindle
  • Compact structure with internal-motor design (for standard-type bed)
  • Ergonomic design for convenient access to chuck and tool



Description Unit SE2200LMA
Max Turning Dia inch 13.75″
Max Turning Length inch 12.16″
Chuck Size inch 6″
Driving Method Belt
Spindle RPM r/min 6,000
Spindle Output HP 20
Spindle Torque lbf.ft 93
Travel(X/Z) inch 8.3″/22″
Rapid Travel(X/Z) m/min 1181 / 1417
Slide Type Roller LM Guide
No. of Tools EA 12
Tool Size inch 0.75″/1.25″
Milling Tool Speed r/min 6000
Mill Motor Power HP 3.69
