Compare Nakamura Tome SC450L with other machines in its class 12 inch, 15 inch, 18 inch, Horizontal Turning Centers, Live Tooling, Live Tooling, Live Tooling & Sub-Spindle, Live Tooling & Sub-Spindle, Live Tooling & Sub-Spindle, Live Tooling Turret, Nakamura Tome, Standard Turret, Standard Turret, Standard Turret
Specifications:
| Capacity | ||||
|---|---|---|---|---|
| Max. turning diameter | 18.9 (480) in (mm) | |||
| Max. turning length | 60 (1520) in (mm) | |||
| Bar capacity | 3.2 (81) or 3.5 ( 90mm ) in (mm) | |||
| Chuck size | 12 (305), 15 (381) or 18 (457) in (mm) | |||
| Axis travel | ||||
| Slide travel (X) | 12.7 (322.5) in (mm) | |||
| Slide travel (Z) | 63.4 (1610) in (mm) | |||
| Slide travel (Y) | ±3 (75)(op.) in (mm) | |||
| Slide Travel (B) | ||||
| Rapid feed (X) | 472.5 (12) in/min (m/min) | |||
| Rapid feed (Z) | 709 (18) in/min (m/min) | |||
| Rapid feed (B) | ||||
| Rapid feed (Y) | 236 (6)(op.) in/min (m/min) | |||
| Spindle | ||||
| Spindle speed | 2500 rpm | |||
| Spindle Speed Range | Stepless | |||
| Spindle Nose | A2-8 | |||
| Hole Through Draw Tube | 3.3 (82) in (mm) | |||
| C-AXIS | ||||
| Least Input Increment | 1E-3 degree | |||
| Turret | ||||
| Number of Tool Stations | 12 | |||
| Rotary system/Number of driven-tool stations | 12 | |||
| MILLING TOOLS | ||||
| Spindle Speed | 3600 rpm | |||
| Number of Milling-Tool Stations | 12 | |||
| ROTATING TOOL | ||||
| Rotary System | Individual Rotation | |||
| Spindle Speed | 3600 rpm | |||
| Spindle Speed Range | Stepless | |||
| Number of Rotation Tool Station | 12 | |||
| DRIVE MOTOR POWER | ||||
| Main Spindle | 40 HP | |||
| Driven Tool Spindle | 7.5 HP | |||
| TAILSTOCK (OP.) | ||||
| Quill Diameter | 4.8 (120) in (mm) | |||
| Quill Taper | MT-4 (built-in center) | |||
| Quill Stroke | Servo Tailstock 58.4 in Stroke in (mm) | |||
| General | ||||
| Machine weight | 19842 (9000) lbs (kg) | |||
