Hyundai Wia F660M

cnc machine qoute
Roll over image to zoom in
Click to open expanded view

Compare Hyundai Wia F660M with other machines in its class , , ,

In stock

Travel (X/Y/Z)
55.12" / 26" / 25"

Specifications

Description Unit F660M
Table Size in 63×25.59
Max. Load Capacity kg 1,300
Spindle Driving Method – Built in
Spindle Taper – BBT40
Spindle RPM r/min 15,000
Spindle Power hp 33.5/30
Spindle Torque ft.lbs 123/70
Travel(X/Y/Z) in 55.12/26/25
Rapid Feed Rate(X/Y/Z) in/min 1417/1417/1181
Slide Type – LM
No. of Tools EA 24
Tool Change Time
(Chip To Chip)		 sec 3.9

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

Categories: , , ,

Features

  • Main spindle equipped with high-precision angular contact bearing
  • Built-in main spindle for processing high quality molds
  • Semi servo ATC for shortest tool exchange time
  • Y-axis with 4 guideways for superb rigidity and smooth motion (F660M)
  • Maximum feed power with roller guide way on all axis
  • Hyundai WIA mold package for optimal processing of mold parts
  • Latest SIEMENS 828D control equipped with exceptional processing software (F660M)

Specifications (metric)

Description Unit F550M F660M
Table Size mm 1,200×550 1,600×650
Max. Load Capacity kg 800 1,300
Spindle Driving Method – Built in
Spindle Taper – BBT40
Spindle RPM r/min 15,000
Spindle Power kW 25/22
Spindle Torque N.m 167/95
Travel(X/Y/Z) mm 1,100/550/520 1,400/660/635
Rapid Feed Rate(X/Y/Z) m/min 36/36/30
Slide Type – LM
No. of Tools EA 24
Tool Change Time
(Chip To Chip)		 sec 3.61 3.9

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

Specifications

Description Unit F550M F660M
Table Size in 47.24×21.65 63×25.59
Max. Load Capacity kg 800 1,300
Spindle Driving Method – Built in
Spindle Taper – BBT40
Spindle RPM r/min 15,000
Spindle Power hp 33.5/30
Spindle Torque ft.lbs 123/70
Travel(X/Y/Z) in 43.3/21.65/20.47 55.12/26/25
Rapid Feed Rate(X/Y/Z) m/min 1417/1417/1181
Slide Type – LM
No. of Tools EA 24
Tool Change Time
(Chip To Chip)		 sec 3.61 3.9

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
