Compare Yama Seiki GV-1200 with other machines in its class 49.2 inches - 22, Vertical Turning Centers
Specifications
| Description | Unit | GV-1200 | |
| CAPACITY | Max. swing diameter | mm(in) | 1600 mm (63″) |
| Max. turning diameter | mm(in) | 1352 mm (53.2″) | |
| Max. Turning Length | mm(in) | 1300 mm (51.2″) | |
| SPINDLE | Chuck Size | (in) | 49.2″ |
| Spindle bearing diameter | mm(in) | Ø 423 mm ( 16.65″ ) | |
| Spindle speed range | r/min | 25 ~ 350 RPM | |
| Spindle Speed (rpm) | r/min | 25 RPM | |
| Motor output ( cont. / 30 min.) | HP/kW | 25 HP ( 18.5 Kw )/ 30 HP ( 22 Kw ) | |
| Torque (Max/Cont.) | ft.lbs | 12841/10558 | |
| Spindle Type | – | Fanuc α 40 / 3,000i | |
| Spindle Nose | – | A2-11 | |
| FEED | Travel (X/Z) | mm(in) | 36.81” (935 mm) / 35.43” (900mm) |
| Rapid Travel (X/Z) | in/min | 472 / 393.7 | |
| Slide Type | – | ||
| Motor output ( Con. ) | HP (KW) | 50 HP ( 37 kW ) | |
| Motor output ( 30 min. ) | HP (KW) | 60 HP ( 45 kW ) | |
| Feed rates | in/min | 197 | |
| BLOCK TOOL | No. of Tool / Stations | EA | 16 |
| Tool Size | OD mm(in) | ||
| ID mm(in) | |||
| TANK CAPACITY | Coolant Tank | Gallon / litre | 130 / 400 L |
| Lubricating Tank | ℓ(gel) | ||
| POWER SUPPLY | Electric Power Supply | kVA | 100 kVA |
| Thickness of Power Cable | Sq | ||
| Voltage | V/Hz | AC 200 / 220 + 10% to – 15% 3 phase | |
| MACHINE | Dimensions (L×WxH) |
mm(in) | 185.03″ x 196.85″ x 194.88″ ( 4,700 x 5,000 x 4,950 mm ) |
| Weight | kg(lb) | 23,500 kg ( 51,700 lb ) | |
| NC | Controller | FANUC Oi-TD |
