Compare Hyundai Wia L400MC with other machines in its class 15 inch, 18 inch, Horizontal Turning Centers, Hyundai Wai, Live Tooling Turret, Live Tooling Turret
Specifications
| Description | Unit | L400MC |
|---|---|---|
| Max Turning Dia | inch | 22″ |
| Max Turning Length | inch | 46.5″ |
| Chuck Size | inch | 15″ |
| Driving Method | – | GEAR |
| Spindle RPM | r/min | 2,000 |
| Spindle Output (max/cont.) | hp | 50/40 |
| Spindle Torque (max/cont.) | ft.lbs | 2266/1837 |
| Travel(X/Z) | inch | 12.6″/47.2″ |
| Rapid Travel(X/Z) | in/min | 787/984 |
| Slide Type | – | BOX |
| No. of Tools | EA | 12 |
| Tool Size (ID/OD) | inch | 1.25″ / 2.5″ |
| Milling Tool Speed | r/min | 4,000 |
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
