Hyundai Wia iCUT400TD

cnc machine qoute

Brand: HYUNDAI WIA

Roll over image to zoom in

Compare Hyundai Wia iCUT400TD with other machines in its class 30 Taper, Hyundai Wia Vertical Drill Tap Centers, Vertical Drill Tap Centers

Status:In stock

Travel(X/Y/Z)
20.5″/15.7″/13″

Description	Unit	i-CUT400TD
Table Size	inch	2 – 25.6″×15.7″
Max. Load Capacity	lb	2 – 551
Spindle Driving Method	–	Direct
Spindle Taper	–	BBT30
Spindle RPM	r/min	12,000
Spindle Power	HP	18.9/5.5
Spindle Torque	lbf.ft	33.2/15.5
Travel(X/Y/Z)	inch	20.5″/15.7″/13″
Rapid Feed Rate(X/Y/Z)	m/min	56/56/56
Slide Type	–	LM
No. of Tools	EA	14
Tool Change Time (Chip To Chip)	sec	1.74

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

Categories: 30 Taper, Hyundai Wia Vertical Drill Tap Centers, Vertical Drill Tap Centers

Features

Shortens setting time for materials with a dual table system
Direct-connection, high-speed spindle system design (15,000rpm)
Servo motor-driven ATC (C-C time: 1.72 sec.)
Shortens non-cutting time with rapid feed (56m/min.)

Specifications (metric)

Description	Unit	i-CUT400TD
Table Size	mm	2 – 650×400
Max. Load Capacity	kg	2 – 250
Spindle Driving Method	–	Direct
Spindle Taper	–	BBT30
Spindle RPM	r/min	12,000
Spindle Power	kW	14.1/4.1
Spindle Torque	N.m	45/21
Travel(X/Y/Z)	mm	520/400/330
Rapid Feed Rate(X/Y/Z)	m/min	56/56/56
Slide Type	–	LM
No. of Tools	EA	14
Tool Change Time (Chip To Chip)	sec	1.74

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

Description	Unit	i-CUT400TD
Table Size	inch	2 – 25.6″×15.7″
Max. Load Capacity	lb	2 – 551
Spindle Driving Method	–	Direct
Spindle Taper	–	BBT30
Spindle RPM	r/min	12,000
Spindle Power	HP	18.9/5.5
Spindle Torque	lbf.ft	33.2/15.5
Travel(X/Y/Z)	inch	20.5″/15.7″/13″
Rapid Feed Rate(X/Y/Z)	m/min	56/56/56
Slide Type	–	LM
No. of Tools	EA	14
Tool Change Time (Chip To Chip)	sec	1.74

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
