• Specifications

    DescriptionUnitGA-2600L
    CAPACITYMax. / Swing over saddlemm(in)580 mm (22.8″)
    Max. Turning Diametermm(in) 351 mm (13.8″)
    Max. Turning Lengthmm(in)606 mm (23.85″)
    Bar Capacitymm(in)64 mm (2.5’)
    SPINDLEChuck Size(in)(10″)
    Hole through spindlemm(in)66mm (2.59”)
    Spindle Speed (rpm)rpm4,000 rpm
    Motor output ( cont. / 30 min.)Hp / kW15 / 20 HP (11 / 15 kW)
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeFANUC
    Spindle NoseA2-8
    FEEDTravel (X/Z)mm(in)165mm (6.50”) / 330mm (12.99”)
    Rapid Travel (X/Z)m/min24m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)2.1 HP(1.6kW)
    Z-axis servo motorHP (KW)4 HP (3.0kW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)25mm(1”)
    ID   mm(in)40mm(1”)
    TANK CAPACITYCoolant TankGallon / litre55 gal. (200L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA26kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)163″ x 65″ x 73″ ( 4,132 x 1,630 x 1,875 mm )
    Weightkg(lb)3,500kg (7,700lb)
    NCControllerFANUC Oi-TC
  • Specifications

    DescriptionUnitGA-2600C
    CAPACITYMax. / Swing over saddlemm(in)400 mm (15.74″)
    Max. Turning Diametermm(in) 350 mm (13.77″)
    Max. Turning Lengthmm(in)606 mm (23.86″)
    Bar Capacitymm(in)65 mm (2.55’)
    SPINDLEChuck Size(in)(10″)
    Hole through spindlemm(in)66mm (2.59”)
    Spindle Speed (rpm)rpm4,000 rpm
    Motor output ( cont. / 30 min.)Hp / kW20.45 / 25.22 HP (15 / 18.5 kW)
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeDirect Belt Drive
    Spindle NoseA2-8
    FEEDTravel (X/Z)mm(in)165mm (6.50”) / 330mm (12.99”)
    Rapid Travel (X/Z)m/min24m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)2.1 HP(1.6kW)
    Z-axis servo motorHP (KW)4 HP (3.0kW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)25mm(0.98”)
    ID   mm(in)40mm(1”)
    TANK CAPACITYCoolant TankGallon / litre55 gal. (200L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA26kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)78″ x 92″ x 68″ ( 1,975 x 2,235 x 1,725 mm )
    Weightkg(lb)3,500kg (7,700lb)
    NCControllerFANUC Oi-TC
  • Specifications

    DescriptionUnitGA-2800L
    CAPACITYMax. / Swing over saddlemm(in)580 mm (22.8″)
    Max. Turning Diametermm(in)351 mm (13.8″)
    Max. Turning Lengthmm(in)574 mm (22.6″)
    Bar Capacitymm(in)76 mm (3’)
    SPINDLEChuck Size(in)(10″)
    Hole through spindlemm(in)90mm (3.54”)
    Spindle Speed (rpm)rpm3,500 rpm
    Motor output ( cont. / 30 min.)Hp / kW15 / 20 HP (11 / 15 kW)
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeDrive Belt drive
    Spindle NoseA2-8
    FEEDTravel (X/Z)mm(in)47.24″ + 1.18″ ( 1,200 mm + 30 mm )
    Rapid Travel (X/Z)m/min24m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)2.1 HP(1.6 kW)
    Z-axis servo motorHP (KW)4 HP (3.0 kW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)25mm(1”)
    ID   mm(in)40mm(1”)
    TANK CAPACITYCoolant TankGallon / litre55 gal. (200L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA26kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)163″ x 65″ x 73″ ( 4,132 x 1,630 x 1,875 mm )
    Weightkg(lb)10,120lbs. ( 4,600 Kg )
    NCControllerFANUC Oi-TC
  • Specifications

    DescriptionUnitGA-2800C
    CAPACITYMax. / Swing over saddlemm(in)580 mm (22.8″)
    Max. Turning Diametermm(in)351 mm (13.8″)
    Max. Turning Lengthmm(in)259 mm (10.2″)
    Bar Capacitymm(in)76 mm (3’)
    SPINDLEChuck Size(in)(10″)
    Hole through spindlemm(in)90mm (3.54”)
    Spindle Speed (rpm)rpm3,500 rpm
    Motor output ( cont. / 30 min.)Hp / kW15 / 20 HP (11 / 15 kW)
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeDrive Belt drive
    Spindle NoseA2-8
    FEEDTravel (X/Z)mm(in)205mm (8.07”) / 350mm (13.77”)
    Rapid Travel (X/Z)m/min20m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)2.1 HP(1.6 kW)
    Z-axis servo motorHP (KW)4 HP (3.0 kW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)25mm(1”)
    ID   mm(in)40mm(1”)
    TANK CAPACITYCoolant TankGallon / litre38 gal. (145L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA26kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in) 1,995 x 2,235 x 1,725 mm ( 78.5″ x 87.9″ x 67.9″ )
    Weightkg(lb)3,500kg (7,700lb)
    NCControllerFANUC Oi-TD
  • Specifications

    DescriptionUnitGA-3000L
    CAPACITYMax. / Swing over saddlemm(in)599 mm (23.6″)
    Max. Turning Diametermm(in)500 mm (19.7″)
    Max. Turning Lengthmm(in)630 mm (24.8″)
    Bar Capacitymm(in)76 mm (3’)
    SPINDLEChuck Size(in)(10″)
    Hole through spindlemm(in)90mm (3.54”)
    Spindle Speed (rpm)rpm2,000 rpm
    Motor output ( cont. / 30 min.)Hp / kW18.5 / 22 kW ( 25 / 30 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeDrive Belt drive
    Spindle NoseA2-8
    FEEDTravel (X/Z)mm(in)260mm(10.23”) / 630mm (24.80”)
    Rapid Travel (X/Z)m/min24m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)4 HP(2.7 kW)
    Z-axis servo motorHP (KW)6 HP (4.5 kW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)25mm(1”)
    ID   mm(in)40mm(1”)
    TANK CAPACITYCoolant TankGallon / litre38 gal. (145L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA38kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)2,845 x 1,965 x 1,910 ( 112.0″ x 77.4″ x 75.1″)
    Weightkg(lb)5,800 kg ( 12,760 lb )
    NCControllerFANUC Oi-TD
  • Specifications

    DescriptionUnitGS-2600L
    CAPACITYMax. / Swing over saddlemm(in)671 mm (26.4″)
    Max. Turning Diametermm(in)419 mm (16.5″)
    Max. Turning Lengthmm(in)600 mm (23.6″)
    Bar Capacitymm(in)64 mm (2.5’)
    SPINDLEChuck Size(in)(10″)
    Hole through spindlemm(in)76mm (2.99”)
    Spindle Speed (rpm)rpm4,000 rpm
    Motor output ( cont. / 30 min.)Hp / kW20 / 25 HP (15 / 18.5 kW)
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeBelt-drive
    Spindle NoseA2-8
    FEEDTravel (X/Z)mm(in)300mm (11.81”) / 780mm (30.69”)
    Rapid Travel (X/Z)m/min30m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)3.6 HP(2.7 kW)
    Z-axis servo motorHP (KW)6.0 HP (4.5kW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)25mm(1”)
    ID   mm(in)40mm(1”)
    TANK CAPACITYCoolant TankGallon / litre95 gal. (300L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA40kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in) 4,520 × 2,200 × 1,870 mm 177.95″ x 86.61″ x )
    Weightkg(lb)6,500kg (14,330lb)
    NCControllerFANUC Oi-TD
  • Specifications

    DescriptionUnitGS-2800L
    CAPACITYMax. / Swing over saddlemm(in)671 mm (26.4″)
    Max. Turning Diametermm(in)419 mm (16.5″)
    Max. Turning Lengthmm(in)599 mm (23.6″)
    Bar Capacitymm(in)76 mm (3’)
    SPINDLEChuck Size(in)(10″)
    Hole through spindlemm(in)90mm (3.54”)
    Spindle Speed (rpm)rpm3,500 rpm
    Motor output ( cont. / 30 min.)Hp / kW15 / 18.5 kW ( 20 / 25 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeBelt-drive
    Spindle NoseA2-8
    FEEDTravel (X/Z)mm(in)300mm(11.81”)
    Rapid Travel (X/Z)m/min30m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)2.7 HP(3.6 kW)
    Z-axis servo motorHP (KW)4.5 HP (6.0 kW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)25mm(1”)
    ID   mm(in)40mm(1”)
    TANK CAPACITYCoolant TankGallon / litre95 gal. (360L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA40kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)4,520 × 2,200 × 1,870 mm 177.95″ x 86.61″ x 73.62 )
    Weightkg(lb)8,500 kg (18,735 lb)
    NCControllerFANUC Oi-TD
