Specifications
TTC300-52 TTC300-65 Swing Diameter 15.75″ 15.75″ Max. Turning Diameter 7.87″ 7.87″ Max. Turning Length 15.75″ 15.75″ X1 / X2/ Z-axis 7.1 / 4.33 / 17.72 in 7.1 / 4.33 / 17.72 in Y-axis (option) +1.57 / -1.57 in +1.57 / -1.57 in Axes Rapid Traverse X / Y / Z 590.5 / 590.5 / 944.9 inch/min 590.5 / 590.5 / 944.9 inch/min Spindle 1 Max. Spindle Speed 5000 rpm 4000 rpm (option 5000rpm) Spindle Nose A6/DIN A8/DIN Chuck Diameter 8.27″ 9.84″ Bar Capacity 2.05″ 2.56″ Performance Pmax 31.5 HP 45.6 HP Max Torque 111 ft-lb 240 ft-lb Spindle 2 Max. Spindle Speed 7000 rpm 7000 rpm Spindle Nose 3.94″ 3.94″ Chuck Diameter 6.50″ 26.50″ Spindle Bore 1.65″ 1.65″ Performance Pmax 18.5 HP 18.5 HP Max Torque 139.4 lb/ft 139.4 lb/ft Turret Number of tools stations 12 + 12 (BMT45) 12 + 12 (BMT45) Number of driven tools (options) all all Toolholder BMT45 BMT45 Max. Speed of Driven Tools 6000 rpm 6000 rpm Performance Pmax 22.1 HP 22.1 HP Max Torque 25.8 ft-lb 25.8 ft-lb General Dimensions L x W x H 98.4 x 74.8 x 85.24 in 106.3 x 74.8 x 85.24 in Weight 10,150 lbs 11,255 lbs -
Specifications
T600-65 T600-85 Swing Diameter 23.6″ 23.6″ Max. Turning Diameter 15.75″ 15.75″ Max. Turning Length 25.59″ 25.59″ X1 / Z-axis + 10.83″ / – 1.57″ + 10.83″ / – 1.57″ Axes Rapid Traverse X / Y / Z 590.5 / 590.5 / 944.9 inch/min 590.5 / 590.5 / 944.9 inch/min Spindle 1 Max. Spindle Speed 4000 rpm (option 5000 rpm) 3200 rpm (option 4000rpm) Spindle Nose A8/DIN A8/DIN Chuck Diameter 9.84″ 9.84″ Spindle Bore 2.56″ 3.35″ Performance Pmax 34 kW 34 kW Max Torque 240 ft-lb 240 ft-lb Spindle 2 Max. Spindle Speed 6000 rpm 6000 rpm Spindle Nose 4.33″ 4.33″ Chuck Diameter 6.5″ 6.5″ Spindle Bore 1.65″ 1.65″ Performance Pmax 15 kW 15 kW Max Torque 70 ft-lb 70 ft-lb Turret Number of tools stations 16 (BMT45) 16 (BMT45) Number of driven tools (options) all all Toolholder BMT45 BMT45 Max. Speed of Driven Tools 6000 rpm 6000 rpm Performance Pmax 16.5 kW 16.5 kW Max Torque 25.8 ft-lb 25.8 ft-lb General Dimensions L x W x H 110″ x 68.9″ x 82.3″ 110″ x 68.9″ x 82.3″ Weight 12,800 lbs 13,900 lbs -
Specifications
T600-65 T600-85 Swing Diameter 23.6″ 23.6″ Max. Turning Diameter 15.75″ 15.75″ Max. Turning Length 25.59″ 25.59″ X1 / Z-axis + 10.83″ / – 1.57″ + 10.83″ / – 1.57″ Axes Rapid Traverse X / Y / Z 590.5 / 590.5 / 944.9 inch/min 590.5 / 590.5 / 944.9 inch/min Spindle 1 Max. Spindle Speed 4000 rpm (option 5000 rpm) 3200 rpm (option 4000rpm) Spindle Nose A8/DIN A8/DIN Chuck Diameter 9.84″ 9.84″ Spindle Bore 2.56″ 3.35″ Performance Pmax 34 kW 34 kW Max Torque 240 ft-lb 240 ft-lb Spindle 2 Max. Spindle Speed 6000 rpm 6000 rpm Spindle Nose 4.33″ 4.33″ Chuck Diameter 6.5″ 6.5″ Spindle Bore 1.65″ 1.65″ Performance Pmax 15 kW 15 kW Max Torque 70 ft-lb 70 ft-lb Turret Number of tools stations 16 (BMT45) 16 (BMT45) Number of driven tools (options) all all Toolholder BMT45 BMT45 Max. Speed of Driven Tools 6000 rpm 6000 rpm Performance Pmax 16.5 kW 16.5 kW Max Torque 25.8 ft-lb 25.8 ft-lb General Dimensions L x W x H 110″ x 68.9″ x 82.3″ 110″ x 68.9″ x 82.3″ Weight 12,800 lbs 13,900 lbs -
Specifications
Model TC300 Max swing diameter 15.7″ Max turning diameter 7.9″ Max turning length 15.7″ Stroke X 7″ Stroke Y* +/- 1.6″ Stroke Z 17.7″ Rapid traverse X-axis / Y-axis / Z-axis ( 0.6 / 0.6 / 0.9 ) inches / min Feed screw diameter x pitch X-axis 1″ x 0.2″ Feed screw diameter x pitch Y-axis 1″ x 0.2″ Feed screw diamter x pitch Z1-axis 1.6″ x 0.4″ Feed screw diamter x pitch Z2-axis* 1.6″ x 0.2″ *Option
-
Specifications
Model B1250SLY Maximum bar capacity 3.74” Maximum machining diameter 21.73” Maximum machining length 46” Maximum swing over diameter (bench) 26.7” MAIN SPINDLE Spindle Bore 3.74” Spindle speed range 3,000 RPM Geared headstock 1:1 and 4:1 Spindle motor 40 HP Motor type Wide range Spindle nose ASA A2-8 Y axis stroke 5.5” TURRET Turret indexing time 1 station 0.3 sec/pos Turret indexing type Bi-directional Number of stations 16 SUB- SPINDLE Bar capacity 2.55” Spindle bore 2.99” Spindle speed range (infinitely variable) 4,000 RPM* Spindle drive motor (variable speed) 54HP Spindle nose 6” Flat Nose Slide movement (B-axis) NC control Slide stroke (B-axis) 44.68” Rapid traverse rate (B-axis) 590.5 IPM Spindle positioning programmable M16 to .001 deg. REVOLVING TOOL ATTACHMENT TURRET Number of positions 16 Drive motor-max. rating (Fanuc) 23 HP Speed range 6,000 RPM Engagement time immediate C AXIS CONTROL WITH SPINDLE POSITIONING Spindles Main Spindle positioning Full “C” Minimum command increment 0.001 degree Positioning system Spindle motor Degree of movement Programmable Rapid speed rate 100 RPM GENERAL INFORMATION Voltage required 400 volt AC, 3-phase Air required 80 psi @ 4 CFM MACHINING DIMENSIONS Width 87.4” Height 92.52” Length with chip conveyor 218” Machine weight with chip conveyor 18,519 lbs. ACCURACY Z axis repeatability accuracy +/-.00004” X axis positioning accuracy +/-.00006” C axis positioning accuracy +/-.00005° C axis repeatability +/-.00001° -
Specifications
Model B750SLY Maximum bar capacity 4.02” Maximum machining diameter 18.4” Maximum machining length 29.5” Maximum swing over diameter (bench) 26.7” MAIN SPINDLE Spindle Bore 4.3” Spindle speed range 3,000 RPM Spindle motor 40 HP Motor type Wide range Spindle nose ASA A2-8 Y-axis stroke 5.5” SUB- SPINDLE Bar capacity 1.77” Spindle bore 2.15”
Spindle speed range (infinitely variable) 5,000 RPM*
Spindle drive motor (variable speed) max rating 33HP Spindle nose 5” Flat Nose Slide movement (B-axis) NC control Slide stroke (B-axis) 35”
Rapid traverse rate (B-axis) 945 IPM
Spindle positioning programmable M16 to .001 deg TURRET Turret indexing time 1 station 0.3 sec/pos. (1-station) Turret indexing type Bi-directional Number of stations
16 REVOLVING TOOL ATTACHMENT TURRET Number of positions 16 Drive motor – max. rating (Fanuc) 23 HP
Speed range (infinitely variable) 6,000 RPM Engagement time immediate
C-AXIS CONTROL W/ SPINDLE POSITIONING Spindles Main and Sub Spindle positioning Full “C” Minimum command increment 0.001 degree Positioning system Spindle motor Degree of movement Programmable Rapid speed rate 100 RPM GENERAL INFORMATION Voltage required 400 volt AC, 3-phase Air required 80 psi @ 4 CFM Amperage Draw 75 Amp. MACHINING DIMENSIONS Width 80” Height 88” Length with chip conveyor 200” Machine weight with chip conveyor 16,755 lbs. ACCURACY Z axis repeatability accuracy +/-.00004” X axis positioning accuracy +/-.00006” C axis positioning accuracy +/-.00005° C axis repeatability +/-.00001° NOTE: Horsepower given are the 30 min. ratings.
* Chuck RPM limitations may apply.
-
Specifications
Model B750SL Maximum bar capacity 3.22” Maximum machining diameter 18.4” Maximum machining length 29.5” Maximum swing over diameter (bench) 26.7” MAIN SPINDLE Spindle Bore 4.17” Spindle speed range 3,000 RPM Spindle motor 40 HP Motor type Wide range Spindle nose ASA A2-8 SUB- SPINDLE Bar capacity 1.77” Spindle bore 2.15”
Spindle speed range (infinitely variable) 5,000 RPM*
Spindle drive motor (variable speed) max rating 33HP Spindle nose 5” Flat Nose Slide movement (B-axis) NC control Slide stroke (B-axis) 35”
Rapid traverse rate (B-axis) 945 IPM
Spindle positioning programmable M16 to .001 deg TURRET Turret indexing time 1 station 0.3 sec/pos. (1-station) Turret indexing type Bi-directional Number of stations
16 REVOLVING TOOL ATTACHMENT TURRET Number of positions 16 Drive motor – max. rating (Fanuc) 23 HP
Speed range (infinitely variable) 6,000 RPM Engagement time immediate
C-AXIS CONTROL W/ SPINDLE POSITIONING Spindles Main and Sub Spindle positioning Full “C” Minimum command increment 0.001 degree Positioning system Spindle motor Degree of movement Programmable Rapid speed rate 100 RPM GENERAL INFORMATION Voltage required 400 volt AC, 3-phase Air required 80 psi @ 4 CFM Amperage Draw 75 Amp. MACHINING DIMENSIONS Width 80” Height 88” Length with chip conveyor 200” Machine weight with chip conveyor 16,755 lbs. ACCURACY Z axis repeatability accuracy +/-.00004” X axis positioning accuracy +/-.00006” C axis positioning accuracy +/-.00005° C axis repeatability +/-.00001° -
Specifications
Model B1250LY Maximum bar capacity 3.74” Maximum machining diameter 21.73” Maximum machining length 46” Maximum swing over diameter (bench) 26.7” MAIN SPINDLE Spindle Bore 3.74” Spindle speed range 3,000 RPM Geared headstock 1:1 and 4:1 Spindle motor 40 HP Motor type Wide range Spindle nose ASA A2-8 Y axis stroke 5.5” TURRET Turret indexing time 1 station 0.3 sec/pos Turret indexing type Bi-directional Number of stations 16 TAILSTOCK Positioning travel 44.88” Quill Stroke 3.93” Quill diameter 3.34” Cylinder area sq. in 17.23 Max Thrust 2,645.5lbs Flange for live center MT5 REVOLVING TOOL ATTACHMENT TURRET Number of positions 16 Drive motor-max. rating (Fanuc) 23 HP Speed range 6,000 RPM Engagement time immediate C AXIS CONTROL WITH SPINDLE POSITIONING Spindles Main Spindle positioning Full “C” Minimum command increment 0.001 degree Positioning system Spindle motor Degree of movement Programmable Rapid speed rate 100 RPM GENERAL INFORMATION Voltage required 400 volt AC, 3-phase Air required 80 psi @ 4 CFM MACHINING DIMENSIONS Width 87.4” Height 92.52” Length with chip conveyor 218” Machine weight with chip conveyor 18,519 lbs. ACCURACY Z axis repeatability accuracy +/-.00004” X axis positioning accuracy +/-.00006” C axis positioning accuracy +/-.00005° C axis repeatability +/-.00001° -
Specifications
Model B1250L Maximum bar capacity 3.74” Maximum machining diameter 17.8” Maximum machining length 46” Maximum swing over diameter (bench) 26.7” MAIN SPINDLE Spindle Bore 3.74” Spindle speed range 3,000 RPM Geared headstock 1:1 and 4:1 Spindle motor 51 HP Motor type Wide range Spindle nose ASA A2-8 TURRET Turret indexing time 1 station 0.3 sec/pos Turret indexing type Bi-directional Number of stations 16 TAILSTOCK Positioning travel 51.2” Quill Stroke 6” Quill diameter 4.5” Cylinder area sq. in 17.23 Max Thrust 2,645.5lbs Flange for live center MT5 REVOLVING TOOL ATTACHMENT TURRET Number of positions 16 Drive motor-max. rating (Fanuc) 23 HP Speed range 6,000 RPM Engagement time immediate C AXIS CONTROL WITH SPINDLE POSITIONING Spindles Main Spindle positioning Full “C” Minimum command increment 0.001 degree Positioning system Spindle motor Degree of movement Programmable Rapid speed rate 100 RPM GENERAL INFORMATION Voltage required 400 volt AC, 3-phase Air required 80 psi @ 4 CFM MACHINING DIMENSIONS Width 86.2” Height 87.5” Length with chip conveyor 218” Machine weight with chip conveyor 18,519 lbs. ACCURACY Z axis repeatability accuracy +/-.00004” X axis positioning accuracy +/-.00006” C axis positioning accuracy +/-.00005° C axis repeatability +/-.00001° -
Specifications
Model B750LY Maximum bar capacity 3.75” Maximum machining diameter 18.4” Maximum machining length 29.5” Maximum swing over diameter (bench) 26.7” MAIN SPINDLE Spindle Bore 4.17” Spindle speed range 3,000 RPM Spindle motor 53 HP Motor type Wide range Spindle nose ASA A2-8 Y-axis stroke 5.5”
TURRET Turret indexing time 1 station 0.3 sec/pos. (1-station) Turret indexing type Bi-directional Number of stations 16 REVOLVING TOOL ATTACHMENT TURRET Number of positions 16 Drive motor – max. rating (Fanuc) 23 HP Speed range (infinitely variable) 6,000 RPM Engagement time immediate C-AXIS CONTROL W/ SPINDLE POSITIONING Spindles Main Spindle positioning Full “C” Minimum command increment 0.001 degree Positioning system Spindle motor Degree of movement Programmable Rapid speed rate 100 RPM GENERAL INFORMATION Voltage required 400 volt AC, 3-phase Air required 80 psi @ 4 CFM Amperage Draw 75 Amp. MACHINING DIMENSIONS Width 80” Height 87.5” Length with chip conveyor 157.5” Machine weight with chip conveyor 16,755 lbs. ACCURACY Z axis repeatability accuracy +/-.00004” X axis positioning accuracy +/-.00006” C axis positioning accuracy +/-.00005° C axis repeatability +/-.00001° -
Specifications
Model B1250L Barrel Maximum bar capacity 3.74” Maximum machining diameter 17.8” Maximum machining length 46” Maximum swing over diameter (bench) 26.7” MAIN SPINDLE Spindle Bore 3.74” Spindle speed range 3,000 RPM Geared headstock 1:1 and 4:1 Spindle motor 51 HP Motor type Wide range Spindle nose ASA A2-8 TURRET Turret indexing time 1 station 0.3 sec/pos Turret indexing type Bi-directional Number of stations 16 TAILSTOCK Positioning travel 51.2” Quill Stroke 6” Quill diameter 4.5” Cylinder area sq. in 17.23 Max Thrust 2,645.5lbs Flange for live center MT5 C AXIS CONTROL WITH SPINDLE POSITIONING Spindles Main Spindle positioning Full “C” Minimum command increment 0.001 degree Positioning system Spindle motor Degree of movement Programmable Rapid speed rate 100 RPM GENERAL INFORMATION Voltage required 400 volt AC, 3-phase Air required 80 psi @ 4 CFM Amperage Draw 75 AMP MACHINING DIMENSIONS Width 86.2” Height 87.5” Length with chip conveyor 218” Machine weight with chip conveyor 18,519 lbs. ACCURACY Z axis repeatability accuracy +/-.00004” X axis positioning accuracy +/-.00006” C axis positioning accuracy +/-.00005° C axis repeatability +/-.00001°
EUROTECH Canada
Advanced CNC Machinery
Horizontal Turning Centers
Line-Up
Eurotech Horizontal Turning Centers offers Lightning Fast Production of parts in one operation. Designed with all Automation required for Unmanned Operation – Over 10,000 Systems Worldwide. Eurotech delivers the highest Return of Investment.
EUROTECH’S Mission Statement:
“To be the most valued product by our customers by delivering the greatest ROI, through superior speed, knowledge and technology.”
Customer Reviews:
“ I can’t say enough about our five(5) Eurotech machines! These machines are great, not to mention dependable. Our relationship with the service department is bar none!” – Les Richards – Owner, Custom Mold
“ We purchase our first 2 Eurotech Horizontal Turning Centers machines in 1997 and they have been running daily with very little downtime. Eurotech solved our application needs and provides incredible concentricity, in fact we had a CP above 2. We have been so happy with Eurotech machines and support that we have since added an additional 12 machines!” – Bill Coll, Timken Bearing
Browse Eurotech’s Horizontal Turning CNC machines below.
Eurotech Horizontal Turning Centers
Available Option(s):
