Optional Chuck Size | Vertical Turning Centers | Yama Seiki

Optional

  • Specifications

    Description Unit GV-2000
    CAPACITY Max. / Swing Dia. mm(in) Ø 2,050 mm ( 80.7″ )
    Max. Turning Dia. mm(in) Ø 2,000 mm ( 78.7″ )
    Max. Turning Length mm(in) 521 mm (20.5″)
    Bar Capacity mm(in) 32 mm (1.25’)
    SPINDLE Chuck Size (in) (12″)
    Hole through spindle mm(in)
    Spindle Speed (rpm) r/min 3,000 rpm
    Motor output ( cont. / 30 min.) HP/kW 20 HP (15kW) / 25 HP (18.5 kW)
    Motor (Max/Cont.) kW(HP)
    Torque (Max/Cont.) N.m
    Spindle Type Belt
    Spindle Nose A2-8
    FEED Travel (X/Z) mm(in) 13.78” (305 mm) / 21.65” (550mm)
    Rapid Travel (X/Z) m/min 20m/min
    Slide Type Linear Guide Way
    X-axis servo motor HP (KW) 2.1 HP ( 1.6 kW)
    Z-axis servo motor HP (KW) 4.0 HP ( 3.0 kW)
    BLOCK TOOL No. of Tool / Stations EA 8
    Tool Size OD mm(in) 25mm (1”)
    ID   mm(in) 50 mm (1.97”)
    TANK CAPACITY Coolant Tank Gallon / litre 66.04 gal (250L)
    Lubricating Tank ℓ(gel)
    POWER SUPPLY Electric Power Supply kVA 40 kVA
    Thickness of Power Cable Sq
    Voltage V/Hz
    MACHINE Dimensions
    (L×WxH)
    mm(in) 59.84″ x 86.61″ x 98.42″ ( 1,520 x 2,200 x 2,500 mm )
    Weight kg(lb) 5,000 kg (11,023 lbs.)
    NC Controller FANUC Oi-TD
