• Specifications

    DescriptionUnitGS-4300ML
    CAPACITYMax. / Swing over saddlemm(in)770 mm (30.3″)
    Max. Turning Diametermm(in) 620mm (24.4″)
    Max. Turning Lengthmm(in)818mm (32.2″)
    Bar Capacitymm(in)183 mm (7.2’)
    SPINDLEChuck Size(in)(24″)
    Hole through spindlemm(in)190 mm (7.48″)
    Spindle Speed (rpm)rpm1,200 rpm
    Motor output ( cont. / 30 min.)Hp / kW30 / 37 kW ( 40 / 50 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle Type2-Speed Gear Box
    Spindle NoseA2-15
    FEEDTravel (X/Z)mm(in)350mm (13.78’) / 1,600mm (62.99’)
    Rapid Travel (X/Z)m/min24 m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)
    Z-axis servo motorHP (KW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)32 mm (1”)
    ID   mm(in)60mm (2”)
    TANK CAPACITYCoolant TankGallon / litre105 gal (410L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA65 kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)4,700 × 2,480 × 2,120 mm ( 185″ x 97″ x 84″ )
    Weightkg(lb)11,000 kg ( 24,251 lb )
    NCControllerFANUC Oi-TD
  • Specifications

    DescriptionUnitGS-4300YL
    CAPACITYMax. / Swing over saddlemm(in)770 mm (30.3″)
    Max. Turning Diametermm(in) 620mm (24.4″)
    Max. Turning Lengthmm(in)818mm (32.2″)
    Bar Capacitymm(in)165 mm (6.5’)
    SPINDLEChuck Size(in)(24″)
    Hole through spindlemm(in)190 mm (7.48″)
    Spindle Speed (rpm)rpm1,200 rpm
    Motor output ( cont. / 30 min.)Hp / kW30 / 37 kW ( 40 / 50 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle Type2-Speed Gear Box
    Spindle NoseA2-15
    FEEDTravel (X/Z)mm(in)350mm (13.78’) / 1,600mm (62.99’)
    Rapid Travel (X/Z)m/min24 m/min
    Slide TypeHardened & Ground Box Ways
    X-axis servo motorHP (KW)
    Z-axis servo motorHP (KW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)32 mm (1”)
    ID   mm(in)60mm (2”)
    TANK CAPACITYCoolant TankGallon / litre105 gal (410L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA65 kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)4,700 × 2,480 × 2,120 mm ( 185″ x 97″ x 84″ )
    Weightkg(lb)11,000 kg ( 24,251 lb )
    NCControllerFANUC Oi-TD
  • Specifications

    DescriptionUnitGS-6800ML
    CAPACITYMax. / Swing over saddlemm(in)980 mm (38.6″)
    Max. Turning Diametermm(in) 879mm (34.6″)
    Max. Turning Lengthmm(in)950mm (37.4″)
    Bar Capacitymm(in)260 mm (10.24’)
    SPINDLEChuck Size(in)(24″)
    Hole through spindlemm(in)260 mm (8.07″)
    Spindle Speed (rpm)rpm800 rpm
    Motor output ( cont. / 30 min.)Hp / kW40 / 50 HP ( 30 / 37 kW )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle TypeV-Belt + Gear Box
    Spindle NoseA2-15
    FEEDTravel (X/Z)mm(in)500mm (19.68’) / 1,965mm (77.36’)
    Rapid Travel (X/Z)m/min24 m/min
    Slide TypeBox Way
    X-axis servo motorHP (KW)
    Z-axis servo motorHP (KW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)32 mm (1”)
    ID   mm(in)60mm (2”)
    TANK CAPACITYCoolant TankGallon / litre84 gal (320L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA64 kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)199.21″ x 95.27″ x 101.10″ ( 5,060 x 2,420 x 2,568 mm )
    Weightkg(lb)14,000 kg ( 30,865 lb )
    NCControllerOi-TD
  • Specifications

    DescriptionUnitGS-8000ML
    CAPACITYMax. / Swing over saddlemm(in)1029 mm (40.5″)
    Max. Turning Diametermm(in) 960mm (37.8″)
    Max. Turning Lengthmm(in)1148mm (45.2″)
    Bar Capacitymm(in)320 mm (12.6’)
    SPINDLEChuck Size(in)(24″)
    Hole through spindlemm(in)205 mm (8.07″)
    Spindle Speed (rpm)rpm700 rpm
    Motor output ( cont. / 30 min.)Hp / kW30 / 45 kW ( 40 / 60 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle Type3-Speed Gear
    Spindle NoseA2-15
    FEEDTravel (X/Z)mm(in)525mm (20.66’) / 1,200mm (47.24’)
    Rapid Travel (X/Z)m/min12 m/min
    Slide TypeBox Way
    X-axis servo motorHP (KW)
    Z-axis servo motorHP (KW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)32 mm (1”)
    ID   mm(in)60mm (2”)
    TANK CAPACITYCoolant TankGallon / litre155 gal (590L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA80 kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)5,650 x 3,150 x 3,060 mm ( 222.44″ x 124.01″ x 120.47″ )
    Weightkg(lb)13,700 kg ( 30,200 lb )
    NCControllerFANUC Oi-TD
  • Specifications

    DescriptionUnitGS-8000ML
    CAPACITYMax. / Swing over saddlemm(in)1029 mm (40.5″)
    Max. Turning Diametermm(in) 960mm (37.8″)
    Max. Turning Lengthmm(in)1148mm (45.2″)
    Bar Capacitymm(in)259 mm (10.2’)
    SPINDLEChuck Size(in)(24″)
    Hole through spindlemm(in)205 mm (8.07″)
    Spindle Speed (rpm)rpm800 rpm
    Motor output ( cont. / 30 min.)Hp / kW30 / 45 kW ( 40 / 60 HP )
    Motor (Max/Cont.)kW(HP)
    Torque (Max/Cont.)N.m
    Spindle Type3-Speed Gear
    Spindle NoseA2-15
    FEEDTravel (X/Z)mm(in)525mm (20.66’) / 1,200mm (47.24’)
    Rapid Travel (X/Z)m/min12 m/min
    Slide TypeBox Way
    X-axis servo motorHP (KW)
    Z-axis servo motorHP (KW)
    BLOCK TOOLNo. of Tool / StationsT12
    Tool SizeOD mm(in)32 mm (1”)
    ID   mm(in)60mm (2”)
    TANK CAPACITYCoolant TankGallon / litre155 gal (590L)
    Lubricating Tankℓ(gel)
    POWER SUPPLYElectric Power SupplykVA80 kVA
    Thickness of Power CableSq
    VoltageV/Hz
    MACHINEDimensions
    (L×WxH)
    mm(in)5,650 x 3,150 x 3,060 mm ( 222.44″ x 124.01″ x 120.47″ )
    Weightkg(lb)13,700 kg ( 30,200 lb )
    NCControllerFANUC Oi-TD
