| Model | TC300 |
| Max swing diameter | 15.7″ |
| Max turning diameter | 7.9″ |
| Max turning length | 15.7″ |
| Stroke X | 7″ |
| Stroke Y* | +/- 1.6″ |
| Stroke Z | 17.7″ |
| Rapid traverse X-axis / Y-axis / Z-axis | ( 0.6 / 0.6 / 0.9 ) inches / min |
| Feed screw diameter x pitch X-axis | 1″ x 0.2″ |
| Feed screw diameter x pitch Y-axis | 1″ x 0.2″ |
| Feed screw diamter x pitch Z1-axis | 1.6″ x 0.4″ |
| Feed screw diamter x pitch Z2-axis* | 1.6″ x 0.2″ |
*Option
New Eurotech SPINNER! This German based high tech manufacturer founded in 1949,has grown to over 500 employees and completes more than a thousand advanced, high speed, up to 12 axis CNC turning/milling machines, designed for high precision, high volume, fully automated unattended machining.
High-speed up to 2 -5/8″ universal turn/mill centers with 28.8 HP spindle, Fanuc 32iT, 12-station Y-axis turret, bar feed interface, C-axis, rigid tapping and depending on model, programmable sub-spindle,, and up to 3.3 HP and 6000 RPM live tooling.
