Travel (X/Y/Z)
(159.8"/131.9"/31.5")
(159.8"/131.9"/31.5")
| Model | RB 212 |
|---|---|
| Table Size | 157.4″ x 94.5″ (4,000 mm x 2,400 mm) |
| X-Axis Travel | 159.8″ (4,060 mm) |
| Y-Axis Travel | 131.9″ (3,350 mm) |
| Y-axis Travel for -YM Configuration | 157.4″ (4,000 mm) |
| Z-Axis Travel | 31.5″ (800 mm) |
| Optional Z-axis Travel | 39.4″ (1,000 mm), 47.2″ (1,200 mm), 55.1″ (1,400 mm) |
| Distance from Spindle Nose to Table Top | 7.9″ to 39.4″ (200 mm to 1,000 mm) |
| Distance Between Columns | 137.8″ (3,500 mm) |
| Maximum Table Load | 33,000 lb (15,000 kg) |
| Linear Position Accuracy | ± 0.0006″ (0.015 mm) full travel |
| Linear Repeatability | ± 0.0001″ (0.003 mm) |
| Coolant Tank Capacity | 132 gallon |
| Air Source | 90 psi @ 3.78 CFM |
| Total power Required | AC 220V ±10% (60 kVA) |
| STEEL | |
| ALLOY | |
| STAINLESS STEEL |
Specifications subject to change without notice.
