Specifications
| Description | Unit | LF1600/2SP | LF1600M/2SP |
|---|---|---|---|
| Max Turning Dia | inch | 10.2″ | 10.2″ |
| Max Turning Length | inch | 6.5″ | 6.5″ |
| Chuck Size | inch | 6″ | 6″ |
| Driving Method | – | Belt | Belt |
| Spindle RPM | r/min | 4,500 | 4,500 |
| Spindle Output | HP | 7.4/10 | 7.4/10 |
| Spindle Torque | lbf.ft | 34.6/47.2 | 34.6/47.2 |
| Travel(X/Z) | inch | 5.5″/6.5″ | 5.5″/6.5″ |
| Rapid Travel(X/Z) | m/min | 24/24 | 24/24 |
| Slide Type | – | BOX | BOX |
| No. of Tools | EA | 2 x 10 | 2 x 10 |
| Tool Size | inch | 0.8″/1.3″ | 0.8″/1.3″ |
| Milling Tool Speed | r/min | – | 4000 |
| CNC | – | F31i | F31i |
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalogue.
