Hyundai Wia E160LMA

In stock

DESCRIPTIONUNITE160LMA
Max Turning Diainch7.5″
Max Turning Lengthinch17.7″
Chuck Sizeinch6″
Driving MethodBelt
Spindle RPMr/min6,000
Spindle OutputHP15/20
Spindle Torquelbf.ft38.7/70.4
Travel(X/Z)inch6.5″/18.1″
Rapid Travel(X/Z)in/min1181 / 1181
Slide TypeLM
No. of ToolsEA12
Tool Size (ID/OD)inch0.75″/1.25
Milling Tool Speedr/min4,500

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

Features

  • 45° slanted one-piece rigid bed structure
  • Minimal thermal distortion
  • Machine structure designed to maximize productivity
  • Best in class rapid traverse rate : 30m/min
  • The most reliable high speed servo turret : 0.1sec/step
  • Environmental friendly, separate coolant and lubrication design
  • Compact design, able to install within a limited space.
  • Ergonomic design allows convenient access to chuck and tools
DESCRIPTIONUNITE160AE160LAE160LMA
Max Turning Diainch11″7.5″
Max Turning Lengthinch11.8″20.1″17.7″
Chuck Sizeinch6″
Driving MethodBelt
Spindle RPMr/min6,000
Spindle OutputHP10/1515/20
Spindle Torquelbf.ft26.4/51.638.7/70.4
Travel(X/Z)inch6.5″/13″6.5″/20.9″6.5″/18.1″
Rapid Travel(X/Z)in/min1181 / 1181
Slide TypeLM
No. of ToolsEA12
Tool Size (ID/OD)inch0.75″/1.25
Milling Tool Speedr/min4,500

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
