Specifications
| Description | Unit | L160A | |
| CAPACITY | Swing Over the Bed | in | 23.6″ |
| Max. Turning Dia. | in | 14″ | |
| Max. Turning Length | in | 18.1″ | |
| Bar Capacity | in | 1.8″ | |
| SPINDLE | Chuck Size | in | 6″ |
| Spindle Bore | in | 2.1″ | |
| Spindle Speed (rpm) | r/min | 6,000 [6,000] | |
| Motor (Max/Cont.) | kW(HP) | 11/7.5(14.7/10) [10.8/9(14.5/12)] | |
| Torque (Max/Cont.) | N.m | 70/47.7(51.6/35.2) [69/57.3(50.8/42.2)] | |
| Spindle Type | – | BELT | |
| Spindle Nose | – | A2-5 | |
| FEED | Travel (X/Z) | in | 8.7″/18.1″ |
| Rapid Travel (X/Z) | in/min | 1,417/1,417 | |
| Slide Type | – | X-Axis : Ball Type LM GUIDE, Z-Axis : ROLLER Type LM GUIDE | |
| BLOCK TOOL | No. of Tool | EA | 12 |
| Tool Size | OD in | 1″ | |
| ID in | 1.6″ | ||
| TANK CAPACITY | Coolant Tank | ℓ(gel) | 150 (39.6) |
| Lubricating Tank | ℓ(gel) | 1.8 (0.5) | |
| POWER SUPPLY | Electric Power Supply | kVA | 19 |
| Thickness of Power Cable | Sq | OVER 16 | |
| Voltage | V/Hz | 220/60 (200/50) | |
| MACHINE | Floor Space (L×W) | mm | 2,720×1,685 |
| in | 107.1″×66.3″ | ||
| Height | in | 73.2″ | |
| Weight | kg(lb) | 4,300 (9,480) | |
| NC | Controller | HYUNDAI WIA FANUC i Series [SIEMENS 828D] |
