Hyundai Wia L160LMSA

In stock

Specifications

DescriptionUnitL160LAL160LMAL160LMSA
Max Turning Diainch14″12.2″12.2″
Max Turning Lengthinch22″21.7″21.7″
Chuck Sizeinch6″6″Main 6″
Sub 6″
Driving MethodBeltBeltBelt
Spindle RPMr/min6,0006,0006,000
Spindle OutputHP15/1015/1015/10
Spindle Torquelbf.ft51.6/35.251.6/35.251.6/35.2
Travel(X/Z)inch8.7″/22″8.7″/22″8.7″/22″/23.2″
Rapid Travel(X/Z)m/min36/3636/3636/36/30
Slide TypeLMLMLM
No. of ToolsEA121212
Tool Sizeinch1″/1.6″1″/1.6″1″/1.6″
Milling Tool Speedr/min5,0005,000
CNCH/W FANUC iH/W FANUC iH/W FANUC i

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalogue.

Features

  • Shortened cycle time to improve productivity.
  • Adequate machine structure to produce various products.
  • Adopted angular ball bearing to maintain high-rigidity and low heat absorption.
  • Strengthened Equipment Sturdiness through Structural Analysis
  • 6″ sub chuck expands cutting capacity (Sub Spindle Attachment Machine)
  • Applied BMT turret to cut heavy-duty products (Mill Turret Attachment Machine)
