Hyundai Wia E160C

In stock

DESCRIPTION UNIT E160C
Max Turning Dia in 11
Max Turning Length in 11
Chuck Size inch 8″
Driving Method Belt
Spindle RPM r/min 4,000
Spindle Output (Max/Cont.) hp 14.75/10
Spindle Torque (Max/Cont.) ft.lb 47.5/93
Travel(X/Z) in 6.5/13
Rapid Travel(X/Z) in/min 1181/1181
Slide Type LM
No. of Tools EA 10
Tool Size (ID/OD) in 1/1.25
Milling Tool Speed r/min

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

Hyundai Wia E160C

Features

  • 45° slanted one-piece high rigidity bed structure
  • Least heat distortion, the most stabilized unit structure
  • Able to extend, and high productive machine structure
  • Unbeatable rapid travel speed: 30m/min
  • The most reliable high speed servo turret is adopted: 0.1sec/step
  • Environmental friendly, separate coolant and lubrication design
  • Compact design, able to install within a narrow space.
  • Ergonomic design allows convenient access to chuck and tool

Specifications

DESCRIPTION UNIT E160C E160LC E160LMC
Max Turning Dia in 11 7.5
Max Turning Length in 11 20 17.7
Chuck Size inch 8″
Driving Method Belt
Spindle RPM r/min 4,000
Spindle Output (Max/Cont.) hp 14.75/10 20/14.75
Spindle Torque (Max/Cont.) ft.lb 47.5/93 69.7/126.7
Travel(X/Z) in 6.5/13 6.5/20.8 6.5/18
Rapid Travel(X/Z) in/min 1181/1181 1181/1181 1181/1181
Slide Type LM LM LM
No. of Tools EA 10 10 12
Tool Size (ID/OD) in 1/1.25 1/1.25 0.75/1.25
Milling Tool Speed r/min 4,500

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
