Specifications
| Description | Unit | GS-2000YL | |
| CAPACITY | Max. / Swing over saddle | mm(in) | 815 mm (32.08″) |
| Max. Turning Diameter | mm(in) | 460 mm (18.11″) | |
| Max. Turning Length | mm(in) | 750 mm (29.52″) | |
| Bar Capacity | mm(in) | 52 mm (2.04’) | |
| SPINDLE | Chuck Size | (in) | (8″) |
| Hole through spindle | mm(in) | 66mm (2.59”) | |
| Spindle Speed (rpm) | rpm | 4,800 rpm | |
| Motor output ( cont. / 30 min.) | Hp / kW | 20.45 / 25.22 HP (15 / 18.5 kW) | |
| Motor (Max/Cont.) | kW(HP) | ||
| Torque (Max/Cont.) | N.m | ||
| Spindle Type | – | ||
| Spindle Nose | – | A2-6 | |
| FEED | Travel (X/Z) | mm(in) | 740 / 1,540 mm (29.13”/ 60.62”) |
| Rapid Travel (X/Z) | m/min | 30m/min | |
| Slide Type | – | ||
| X-axis servo motor | HP (KW) | 6.13 HP(4.5kW) | |
| Z-axis servo motor | HP (KW) | 4.09 HP (3.0kW) | |
| BLOCK TOOL | No. of Tool / Stations | T | 12 |
| Tool Size | OD mm(in) | 25mm(0.98”) | |
| ID mm(in) | 40mm(1.57”) | ||
| TANK CAPACITY | Coolant Tank | Gallon / litre | |
| Lubricating Tank | ℓ(gel) | ||
| POWER SUPPLY | Electric Power Supply | kVA | |
| Thickness of Power Cable | Sq | ||
| Voltage | V/Hz | ||
| MACHINE | Dimensions (L×WxH) |
mm(in) | |
| Weight | kg(lb) | ||
| NC | Controller | FANUC |
