Hyundai Wia LV1400

Compare Hyundai Wia LV1400 with other machines in its class , , ,

In stock

Specifications

Description Unit LV1400
Max Turning Dia in 55.12
Max Turning Length in 33.46
Chuck Size in 40
Driving Method Belt
Spindle RPM r/min 492
Spindle Output (max/cont.) hp 50/40hp
Spindle Torque (max/cont.) ft.lbs 5926/4805
Travel(X/Z) in -1.7 ~ +32.48/31.5
Rapid Travel(X/Z) in/min 472/472
Slide Type BOX
No. of Tools EA 12
Tool Size (ID/OD) in 0.75″/1.25″

Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.

Hyundai Wia LV1400

Features

  • Strengthened heavy-duty cutting ability with 2-step geared drive for tables
  • Main spindle designed with cross roller bearing and box guideway in all axes bring rigidity
  • Highly rigid table structure for heavy load
  • Hydraulic cylinder type 3-step moving crossrail structure(LV2000MM)
  • Various Machining provided: Turning, tapping, milling, grinding etc.(LV2000MF/2000MM)
  • Linear scale on all axes as standard
