Specifications
| Description | Unit | LV500R/L | LV500RM/LM |
|---|---|---|---|
| Max Turning Dia | in | 21.65 | 21.65 |
| Max Turning Length | in | 23.62 | 23.62 |
| Chuck Size | in | 15″ | 15″ |
| Driving Method | – | Belt | Belt |
| Spindle RPM | r/min | 2,000 | 2,000 |
| Spindle Output | kW | 18.5/22 | 18.5/22 |
| Spindle Torque | N.m | 693/824 | 693/824 |
| Travel(X/Z) | in | 12.8/24.6 | 12.8/24.6 |
| Rapid Travel(X/Z) | in/min | 787/708 | 787/708 |
| Slide Type | – | LM | LM |
| No. of Tools | EA | 8[12] | 8[12] |
| Tool Size | mm | 32/50 | 32/50 |
| Milling Tool Speed | r/min | – | 3,000 |
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
