$50,000.00
| CNC controller | Fanuc 0i-TC |
| Swing | 29.5″ |
| Maximum Cutting Diameter | 19.7″ |
| Maximum Turning Length | 52″ |
| Travel X axis | 11.4″ |
| Travel Z axis | 53.1″ |
| Guide Ways Boxed on X Linear For Z | Boxed |
| Spindle Nose | A2 8 |
| Max Bar Work Diameter | 3″ |
| Spindle Speed | 3,600 rpm |
| Rapid Traverse X axis | 787 ipm |
| Rapid Traverse Z axis | 945 ipm |
| Turret | 12 Tools |
| Live Tool Max. Speed | – |
| Live Tool Power | 7.5 HP |
| Tool Size (Square Shank) | 1″ sq |
| Tool Size (Round shank) | 2″ |
| Index Time (1 station/1 full rev) | .3 sec |
| Chuck | ( Samwoo Kitagawa ) 12″Main 12″ |
| Tail Stock Quill Diameter | 3.9″ |
| Tail Stock Quill Travel | Manual 4.7″ |
| Tail Stock Body Travel | 53.1″ |
| Tail Stock Quill Internal Taper | MT# 5 |
| Gear Box | 2 Gear Ranges |
| Horsepower(30min./Peak) | 30 HP |
| Torque | 556.9 Ft-lbs |
| Weight | 16,534 lbs |
| Bed | 45 deg  |
